Adamite Rolls

Adamite Rolls

Adamite Rolls, Adamite Steel Rolls, Adamite Rolls & Rings

Adamite rolls have a carbon content of 1.5% to 2.3% with various alloy elements such as Cr, Ni, Mo, and V. Generally, the mass fraction of free carbides is about 6% to 10%, with small hardness drop and high wear resistance. The rolls have high performance, good toughness, significantly reduced consumption, improved surface quality of profiles and rail beams, etc. They are widely used to replace cast steel rolls and low-alloy cast iron rolls, such as large-sized steel rough rolls, profile steel rolling mills, intermediate rolling mills, work rolls in the hot rolling strip continuous mill, etc. The biggest advantage of these rolls is almost no hardness gradient in the working layer.The carbon content and alloy element content of the semi-steel rolls are adjusted according to the applications of the mill rolls and the corresponding heat treatment process is used to control the roll structure with different matrix, carbide content and morphology to meet the requirements of different rolling mills.

Table.1 Chemical Composition %

Symbol C Si MnCr Ni Mo
AD140Ⅰ 1.30-1.50 0.30-0.60 0.70-1.10 0.80-1.20 0.50-1.10 0.20-0.60
AD160Ⅰ 1.50-1.70 0.30-0.60 0.80-1.30 0.80-2.00 ≥0.20 0.20-0.60
AD180-AD200 1.70-2.10 0.30-0.80 0.60-1.20 0.80-3.50 0.50-2.50 0.20-0.80
ADGT 1.40-1.60 0.30-0.80 0.70-1.50 1.00-2.00 1.00-3.00 0.40-0.80
